Product Summary

The AT29C040A-90JI is a 5-volt only in-system Flash Programmable and Erasable Read Only Memory (PEROM). Its 4 megabits of memory is organized as 524,288 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS EEPROM technology, the device offers access times up to 90 ns, and a low 220 mW power dissipation. When the AT29C040A-90JI is deselected, the CMOS standby current is less than 100 μA. The AT29C040A-90JI endurance is such that any sector can typically be written to in excess of 10,000 times. The programming algorithm is compatible with other devices in Atmel’s 5-volt only Flash family.

Parametrics

AT29C040A-90JI absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE with Respect to Ground: -0.6V to +13.5V.

Features

AT29C040A-90JI features: (1)Fast Read Access Time -90 ns; (2)5-volt Only Reprogramming; (3)Sector Program Operation: Single Cycle Reprogram (Erase and Program), 2048 Sectors (256 Bytes/Sector), Internal Address and Data Latches for 256 Bytes; (4)Internal Program Control and Timer; (5)Hardware and Software Data Protection; (6)Two 16K Bytes Boot Blocks with Lockout; (7)Fast Sector Program Cycle Time -10 ms; (8)DATA Polling for End of Program Detection; (9)Low Power Dissipation: 40 mA Active Current, 100 μA CMOS Standby Current; (10)Typical Endurance > 10,000 Cycles; (11)Single 5V ±10% Supply; (12)Green (Pb/Halide-free) Packaging Option.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AT29C040A-90JI
AT29C040A-90JI

Atmel

Flash 4M(512Kx8) 5V ONLY- 90NS IND TEMP

Data Sheet

Negotiable
Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AT29BV010A
AT29BV010A

Other


Data Sheet

Negotiable
AT29BV010A-12JC
AT29BV010A-12JC

Atmel

Flash 1M (128K X 8) 2.7V- 120NS COM TEMP

Data Sheet

Negotiable
AT29BV010A-12JI
AT29BV010A-12JI

Atmel

Flash 1M (128K X 8) 2.7V- 120NS IND TEMP

Data Sheet

Negotiable
AT29BV010A-12JU
AT29BV010A-12JU

Atmel

Flash 1M(128Kx8) 2.7V - 120NS IND TEMP

Data Sheet

Negotiable
AT29BV010A-12TC
AT29BV010A-12TC

Atmel

Flash 1M (128K X 8) 2.7V- 120NS COM TEMP

Data Sheet

Negotiable
AT29BV010A-12TI
AT29BV010A-12TI

Atmel

Flash 1M (128K X 8) 2.7V- 120NS IND TEMP

Data Sheet

Negotiable
