Product Summary

The AK5393VS is a 24bit, 128x oversampling 2ch A/D Converter for professional digital audio systems. The modulator in the AK5393VS uses the new developed Enhanced Dual Bit architecture. This new architecture achieves the wide dynamic range, while keeping much the same superior distortion characteristics as conventional Single Bit way. The AK5393VS performs 117dB dynamic range, so the device is suitable for professional studio equipment such as digital mixer, digital VTR etc.

Parametrics

AK5393VS absolute maximum ratings: (1)Power Supplies: Analog: -0.3 to 6.0 V, Digital: -0.3 to 6.0 V, ; (2)|BGNDDGND|: 0.3 V; (3)Input Current, Any Pin Except Supplies: ±10 mA; (4)Analog Input Voltage: -0.3 to VA+0.3 V; (5)Digital Input Voltage: -0.3 to VD+0.3 V; (6)Ambient Temperature (power applied) : -10 to 70 ℃; (7)Storage Temperature: -65 to 150 ℃.

Features

AK5393VS features: (1)Enhanced Dual Bit ADC; (2)Sampling Rate: 1kHz~108kHz; (3)Full Differential Inputs; (4)S/(N+D): 105dB; (5)DR: 117dB; (6)S/N: 117dB; (7)High Performance Linear Phase Digital AntiAlias filter: Passband: 0~21.768kHz(@fs=48kHz), Ripple: 0.001dB, Stopband: 110dB; (8)Digital HPF & Offset Calibration for Offset Cancel; (9)Power Supply: 5V±5%(Analog), 3~5.25V(Digital); (10)Power Dissipation: 470mW; (11)Package: 28pin SOP; (12)AK5392 Pin compatible.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AK5393VSP-E2
AK5393VSP-E2

IC ADC DGTL AUDIO 24BIT 28SOP
Data Sheet
0-1: $16.58
1-25: $14.93
25-100: $13.68
100-250: $12.85
250-500: $12.02
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AK5358BETP-E2
AK5358BETP-E2

IC ADC AUDIO STER 24BIT 16TSSOP
Data Sheet
0-1: $1.03
1-10: $0.92
10-25: $0.81
25-100: $0.73
100-250: $0.63
250-500: $0.57
500-1000: $0.45
AK5355VTP-E2
AK5355VTP-E2

IC ADC AUDIO STER 16BIT 16TSSOP
Data Sheet
0-1000: $0.94
1000-5000: $0.86
AK5357VTP-E2
AK5357VTP-E2

IC ADC AUDIO STER 24BIT 16TSSOP
Data Sheet
0-1: $1.76
1-25: $1.36
25-100: $1.23
100-250: $1.11
250-500: $0.96
AK5358AETP-E2
AK5358AETP-E2

IC ADC AUDIO STER 24BIT 16TSSOP
Data Sheet
0-1: $1.47
1-25: $1.13
25-100: $1.03
100-250: $0.92
250-500: $0.80
AK5393VSP-E2
AK5393VSP-E2

IC ADC DGTL AUDIO 24BIT 28SOP
Data Sheet
0-1: $16.58
1-25: $14.93
25-100: $13.68
100-250: $12.85
250-500: $12.02
AK5394AVSP-E2
AK5394AVSP-E2

IC ADC AUDIO STER 24BIT 28VSOP
Data Sheet
0-1: $13.20
1-25: $11.88
25-100: $10.89
100-250: $10.23
250-500: $9.57
