Product Summary

The DM9000AEP is a fully integrated and cost-effective low pin count single chip Fast Ethernet controller with a general processor interface, a 10/100M PHY and 4K Dword SRAM. It is designed with low power and high performance process that support 3.3V with 5V IO tolerance. It supports 8-bit and 16-bit data interfaces to internal memory accesses for various processors. The applications of the The DM9000AEP inlucde VoIP CPE (ATA, IP Phone, Video Phone) and IP STB, IPC, Internet Radio. The PHY of the DM9000AEP can interface to the UTP3, 4, 5 in 10Base-T and UTP5 in 100Base-TX with HP Auto-MDIX. It is fully compliant with the IEEE 802.3u Spec. Its auto-negotiation function will automatically configure the DM9000AEP to take the maximum advantage of its abilities. It also supports IEEE 802.3x full- duplex flow control.

Parametrics

DM9000AEP absolute maximum ratings: (1)Product Category: Drivers; (2)Number of Digits: 20; (3)Number of Segments: 160; (4)Package / Case: VSO-56; (5)Maximum Clock Frequency: 400 KHz; (6)Operating Supply Voltage: 8.50V; (7)Maximum Supply Current: 0.12 mA; (8)Maximum Power Dissipation: 400 mW; (9)Maximum Operating Temperature: + 180℃; (10)Minimum Operating Temperature: - 80℃.

Features

DM9000AEP specifications: (1)48-pin LQFP; (2)Supports processor interface: byte/word of I/O command to internal memory data operation; (3)Integrated 10/100M transceiver with HP Auto-MDIX; (4)Supports back pressure mode for half-duplex mode flow control; (5)IEEE802.3x flow control for full-duplex mode; (6)Supports wakeup frame, link status change and magic packet events for remote wake up; (7)Support 100M Fiber interface.; (8)Integrated 16K Byte SRAM; (9)Build in 3.3V to 2.5V regulator; (10)Supports early Transmit; (11)Supports IP/TCP/UDP checksum generation and checking; (12)Supports automatically load vendor ID and product ID from EEPROM; (13)Optional EEPROM configuration; (14)Very low power consumption mode: Power reduced mode (cable detection); Power down mode; Selectable TX drivers for 1:1 or 1.25:1 transformers for additional power reduction; (15)Compatible with 3.3V and 5.0V tolerant I/O.
