Product Summary
The IDT77211L155PQF is a member of IDT family of products for Asynchronous Transfer Mode (ATM) networks. The IDT77211L155PQF performs both the ATM Adaption Layer (AAL). It is fabricated using state-of-the-art CMOS technology. The IDT77211L155PQF is the 155 Mbps ATM SAR contboller for PCI-based networking applications.
Parametrics
IDT77211L155PQF maximum ratings: (1)Supply Voltage: -0.3 to 6.5 V; (2)Input Voltage: VSS-0.3 to VCC+0.3 V; (3)Output Voltage: VSS-0.3 to VCC+0.3 V; (4)Storage Temperature: 0 to 125 ℃.
Features
IDT77211L155PQF features: (1)Operates with ATM networks up to 155.52 Mbps; (2)Up to 16K open transmit connections; (3)Up to 16K simultaneous receive connections; (4)Glue-less integration PCI bus; (5)UTOPIA Interface to PHY; (6)Utility and Management Interface to PHY; (7)Standalone controller: embedded processor not required; (8)Supports high-performance, lowest-cost ATM NIC solution; (9)Supports Big/Little endian on PCI interface.
Diagrams
 |
